Air corrector jets for Mikuni VM 24, 26 and 28mm round slide Mikunis.
- seanbarney41
- Offline
- User
- '79 kz1000 LTD '75 Honda CB750
After installing the air correctors, part throttle operation was immediately great. I just had to jet it back from the former configuration closer to stock. All that is left to do is get the main jets right. The most amazing thing is how easy and straightforward jetting changes have become. No guesswork. Changes yield the results expected so if you go the wrong away, you know it. Not only have the air correctors improved the tune of my 650, they have enabled me to learn so much more about carb tuning.
Please Log in or Create an account to join the conversation.
- Mikaw
- Offline
- Sustaining Member
- Posts: 4831
- Thank you received: 1847
Zed1015, the choke plungers arrived yesterday. Thank you for the diligence in such nice rebuild and in the packaging. They look great, and arrived in perfect condition.
Everything from Zed it top quality and function as depicted please do not hesitate to engage with him for the items he offers, you won’t be disappointed.
Zed1015 is just one example of the members on this forum that really live and breathe all things Kz. Like I have said before they don’t want to help you get your vintage bike just running. They want to help you get you machine running correctly! There a big difference in the two.
1976 KZ 900 A4 kzrider.com/forum/11-projects/613548-1976-kz-900-a4
1976 KZ 900 B1 LTD
1978 KZ 1000 B2 LTD
1980 KZ 750 E1
Kowledge Speaks, But Wisdom Listens.
Jimi Hendrix.
Please Log in or Create an account to join the conversation.
- zed1015
- Topic Author
- Offline
- User
- Posts: 3049
- Thank you received: 1583
Please be sure to send them marked as a gift and declare either zero or a low value.
Anything over £15 attracts vat etc which has to be paid before the package is released and will have to be added to the cost..
I don't have the same issue when sending them back out.
They just go as a large tracked and signed letter ( padded jiffy ) and have always got straight to the destination without any
charges.
They should be sent to me bare with the springs etc removed.
I recommend they are taped to a piece of card to secure them on their journey.
Thanks.
Rob.
AIR CORRECTOR JETS FOR VM CARBS AND ETHANOL RESISTANT VITON CHOKE PLUNGER SEAL REPLACMENT FOR ALL CLASSIC AND MODERN MOTORCYCLE CARBURETTORS
kzrider.com/forum/23-for-sale/611992-air-corrector-jets-
Please Log in or Create an account to join the conversation.
- Mikaw
- Offline
- Sustaining Member
- Posts: 4831
- Thank you received: 1847
zed1015 wrote: Some important advise for anyone sending their plungers from overseas to be re-seated.
Please be sure to send them marked as a gift and declare either zero or a low value.
Anything over £15 attracts vat etc which has to be paid before the package is released and will have to be added to the cost..
I don't have the same issue when sending them back out.
They just go as a large tracked and signed letter ( padded jiffy ) and have always got straight to the destination without any
charges.
They should be sent to me bare with the springs etc removed.
I recommend they are taped to a piece of card to secure them on their journey.
Thanks.
Rob.
Guilty as charged. I’ll do better next time.
1976 KZ 900 A4 kzrider.com/forum/11-projects/613548-1976-kz-900-a4
1976 KZ 900 B1 LTD
1978 KZ 1000 B2 LTD
1980 KZ 750 E1
Kowledge Speaks, But Wisdom Listens.
Jimi Hendrix.
Please Log in or Create an account to join the conversation.
- zed1015
- Topic Author
- Offline
- User
- Posts: 3049
- Thank you received: 1583
It appears that pretty much all Mikuni and most Keihin plungers use the same 8mm diameter head.
This mean that the re-seating process ( along with the problem of leaking seats) isn't confined to just the VM carbs used on the Z's and GS fours but almost any other single, twin, triple or four etc out there that runs 8mm plungers that are no longer available new.
Price remains at £12.50 per plunger + return post tracked and signed worldwide.
Email zed.1015@yahoo.co.uk
AIR CORRECTOR JETS FOR VM CARBS AND ETHANOL RESISTANT VITON CHOKE PLUNGER SEAL REPLACMENT FOR ALL CLASSIC AND MODERN MOTORCYCLE CARBURETTORS
kzrider.com/forum/23-for-sale/611992-air-corrector-jets-
Please Log in or Create an account to join the conversation.
- gordone
- Offline
- Sustaining Member
- Posts: 1391
- Thank you received: 69
1981 KZ650-D4, with 1981 z750L engine (Wiensco 810 big bore).
Project:
www.kzrider.com/forum/11-projects/607213...sr-1981-z750l-engine
Please Log in or Create an account to join the conversation.
- zed1015
- Topic Author
- Offline
- User
- Posts: 3049
- Thank you received: 1583
gordone wrote: These tap is fin to use ?
Hi, Gordone.
YES! Those are the correct size for the air jets.
AIR CORRECTOR JETS FOR VM CARBS AND ETHANOL RESISTANT VITON CHOKE PLUNGER SEAL REPLACMENT FOR ALL CLASSIC AND MODERN MOTORCYCLE CARBURETTORS
kzrider.com/forum/23-for-sale/611992-air-corrector-jets-
Please Log in or Create an account to join the conversation.
- gordone
- Offline
- Sustaining Member
- Posts: 1391
- Thank you received: 69
When you make the threads can I just vaackum clean the metal pieces? Or must I take out all jets and high pressure air clean the carbs....
1981 KZ650-D4, with 1981 z750L engine (Wiensco 810 big bore).
Project:
www.kzrider.com/forum/11-projects/607213...sr-1981-z750l-engine
Please Log in or Create an account to join the conversation.
- zed1015
- Topic Author
- Offline
- User
- Posts: 3049
- Thank you received: 1583
If you are careful you can cut the threads without getting any swarf in the air bleed.gordone wrote: Properly stupid question
When you make the threads can I just vaackum clean the metal pieces? Or must I take out all jets and high pressure air clean the carbs....
I just cut the threads with the carb mouths facing downwards slightly so that the chips fall out.
If you think any swarf has entered the air bleed you can blow compressed air up the main jet to clear it.
AIR CORRECTOR JETS FOR VM CARBS AND ETHANOL RESISTANT VITON CHOKE PLUNGER SEAL REPLACMENT FOR ALL CLASSIC AND MODERN MOTORCYCLE CARBURETTORS
kzrider.com/forum/23-for-sale/611992-air-corrector-jets-
Please Log in or Create an account to join the conversation.
- gordone
- Offline
- Sustaining Member
- Posts: 1391
- Thank you received: 69
If you go some deeper and the jet is not flushing the surface is that a problem?
1981 KZ650-D4, with 1981 z750L engine (Wiensco 810 big bore).
Project:
www.kzrider.com/forum/11-projects/607213...sr-1981-z750l-engine
Please Log in or Create an account to join the conversation.
- zed1015
- Topic Author
- Offline
- User
- Posts: 3049
- Thank you received: 1583
gordone wrote: I understand the tap shall be 8mm deep, but that is because you don’t need deeper?
If you go some deeper and the jet is not flushing the surface is that a problem?
Yes! doesn't need to be any deeper but no problem if it is.
AIR CORRECTOR JETS FOR VM CARBS AND ETHANOL RESISTANT VITON CHOKE PLUNGER SEAL REPLACMENT FOR ALL CLASSIC AND MODERN MOTORCYCLE CARBURETTORS
kzrider.com/forum/23-for-sale/611992-air-corrector-jets-
Please Log in or Create an account to join the conversation.
- gordone
- Offline
- Sustaining Member
- Posts: 1391
- Thank you received: 69
1981 KZ650-D4, with 1981 z750L engine (Wiensco 810 big bore).
Project:
www.kzrider.com/forum/11-projects/607213...sr-1981-z750l-engine
